The following figure shows the settings that display when you configure a cable or fiber connection with a login

and PPTP service.

12. Enter the cable or fiber settings as described in the following table.

DescriptionField

Select the encapsulation, as indicated by your ISP:

• PPTP.Your Internet connection uses Point-to-Point Tunneling Protocol.

• L2TP.Your Internet connection uses Layer Two Tunneling Protocol.

Internet Service Provider

Enter the login name that you use to log in to your Internet service, as indicated by

your ISP.

This login name is often an email address.

Enter the password that you use to log in to your Internet service, as indicated by

your ISP.

Password

Manage the Internet Settings Manually

Nighthawk X4S AC2600 WiFi VDSL/ADSL Modem Router Model D7800
