Technical Specifications for Orbi Satellite Model RBS10
The following table shows the technical specifications for the satellite.
Table 7. Technical specifications for the satellite
DescriptionFeature
TCP/IP, DHCP, Dynamic DNS, and UPnPData and routing protocols
North America: 120V, 60 Hz, input
UK, Australia: 240V, 50 Hz, input
Europe: 230V, 50 Hz, input
All regions (output): 12V, 1A DC output
Power adapter
4.1 x 4.1 x 2.7 in. (104.14 x 104.14 x 68.58 mm)Dimensions
0.54 lb (244.94 g)Weight
0° to 40°C (32º to 104ºF)Operating temperature
90% maximum relative humidity, noncondensingOperating humidity
FCC Part 15, Subpart B, Class B
IECS-003, Class B
EN 55032, EN 55035, Class B
AS/NZS CISPR 32, Class B
Electromagnetic emissions
Maximum wireless signal rate complies with the IEEE 802.11
standard.
4
WiFi
2.4 GHz: Max 400 Mbps
5 GHz Front haul: Max 866 Mbps
5 GHz Back haul: Max 866 Mbps
Radio data rates
IEEE 802.11b/g/n 2.4 GHz–256 QAM support
IEEE 802.11 a/n/ac 5 GHz–256 QAM support
Data encoding standards
Limited by the amount of WiFi network traffic generated by
each node (typically 50–70 nodes).
2.4 GHz: 127
5 GHz (front haul): 127
Maximum number of
computers per wireless
network
User Manual141Supplemental Information
Orbi Whole Home AC1200 Mesh WiFi System
