PL1000v2 and PL1010v2
The hardware features of the PowerLINE PL1000v2 and PL1010v2 adapters are shown
in the following figure. Note that adapters vary by region. Your adapter might look
different.
1
2
3
4 5 6
Figure 2. Hardware features
Power LED1
Ethernet LED2
Pick A Plug LED3
Ethernet port4
Factory Reset button5
Security button6
User Manual7Your PowerLINE Adapter
