Firewall Protection
164
ProSAFE Gigabit Quad WAN SSL VPN Firewall SRX5308
Examples of Firewall Rules
• Examples of Inbound Firewall Rules
• Examples of Outbound Firewall Rules
Examples of Inbound Firewall Rules
IPv4 LAN WAN Inbound Rule: Host a Local Public Web Server
If you host a public web server on your local network, you can define a rule to allow inbound
web (HTTP) requests from any outside IP address to the IP address of your web server at
any time of the day.
Figure 93.
IPv4 LAN WAN Inbound Rule: Allow a Videoconference from Restricted
Addresses
If you want to allow incoming videoconferencing to be initiated from a restricted range of
outside IP addresses, such as from a branch office, you can create an inbound rule (see the
following figure). In the example, CU-SeeMe connections are allowed only from a specified
range of external IP addresses.
