Virtual Private Networking Using IPSec and L2TP Connections
211
ProSAFE Gigabit Quad WAN SSL VPN Firewall SRX5308
Figure 133.
5. Configure a VPN policy on the remote gateway that allows connection to the VPN firewall.
6. Activate the IPSec VPN connection:
a. Select VPN > Connection Status. The Connection Status submenu tabs display with
the IPSec VPN Connection Status screen in view:
Figure 134.
b. Locate the policy in the table, and click the Connect table button. The IPSec VPN
connection becomes active.
Note: When using FQDNs, if the Dynamic DNS service is slow to update
its servers when your DHCP WAN address changes, the VPN tunnel
fails because the FQDNs do not resolve to your new address. If you
have the option to configure the update interval, set it to an
appropriately short time.
