NETGEAR ProSAFE SRX5308 - Page 258

Virtual Private Networking Using IPSec and L2TP Connections
258
ProSAFE Gigabit Quad WAN SSL VPN Firewall SRX5308
Note: Perform these tasks from a computer that has the NETGEAR
ProSafe VPN Client installed.
To configure the VPN client for Mode Config operation, create authentication settings
(phase 1 settings), create an associated IPSec configuration (phase 2 settings), and specify
the global parameters.
Configure the Mode Config Authentication Settings (Phase 1 Settings)
 To create new authentication settings:
1. Right-click the VPN client icon in your Windows system tray, and select Configuration
Panel
. The Configuration Panel screen displays:
Figure 167.
2. In the tree list pane of the Configuration Panel screen, right-click VPN Configuration, and
select New Phase 1.
Figure 168.
