Figure 2. Router LEDs and buttons
Table 1. LED descriptions
DescriptionLED
•
Solid white. The router is ready.
•
Blinking white. The router is not ready, the firmware is upgrading, or the Reset button
was pressed.
•
Off. Power is not supplied to the router.
Power
•
Solid white. An Ethernet connection is established.
•
Blinking white. The port is sending or receiving traffic.
•
Off. No Ethernet cable is connected between the router and the modem.
Internet
•
Solid white. The 2.4 GHz WiFi radio is operating.
•
Blinking. The router is sending or receiving WiFi traffic.
•
Off. The 2.4 GHz WiFi radio is off.
2.4 GHz WiFi
•
Solid white. The 5 GHz WiFi radio is operating.
•
Blinking. The router is sending or receiving WiFi traffic.
•
Off. The 5 GHz WiFi radio is off.
5 GHz WiFi
User Manual11Hardware Setup
Nighthawk AC1750 Smart WiFi Router
