7. Click the Add button.
8.
Specify the settings as described in the following table.
DescriptionField
Enter a name for the VLAN tag group.
The name can be up to 10 characters.
Name
Enter a value from 1 to 4094.VLAN ID
Enter a value from 0 to 7.Priority
If your device is connected to an Ethernet port on the router, select the Wired Ports
check box that corresponds to the Ethernet port on the router that the device is
connected to.
Wired Ports
If your device is connected to your router’s WiFi network, select the Wireless check box
that corresponds to the router’s WiFi network that the device is connected to.
Wireless
Note: You must select at least one Wired Ports or Wireless check box. You can select more than one
check box.
9. Click the Add button.
The VLAN tag group is added.
10. Click the Apply button.
Your settings are saved.
Set Up an IPTV Port to Lease an Intranet Port
You can set up the router to create an Internet Protocol television (IPTV) port that can
lease an IP address from your IPTV service provider. Use this feature only if you subscribe
to an IPTV service and your IPTV service requires an intranet address.
Some IPTV ports cannot work behind NAT because the IPTV port requires an IP address
within the Internet service provider's network (intranet address). You can set up a bridge
connection from the WAN to one of the LAN ports. When IPTV is connected through
WiFi, the home router also must support the bridging of the WAN port to the WiFi
network name (SSID). The designated LAN port or WiFi name becomes an IPTV port
with direct access to the WAN without going through NAT.
User Manual75Network Settings
Nighthawk AC1750 Smart WiFi Router
