NETGEAR RangeMax™ Dual Band Wireless-N Router WNDR3300 User Manual
Customizing Your Network Settings 5-21
v1.1, October 2008
11. Click Apply. The service appears in the Port Triggering Portmap table.
Wireless Repeating (Also Called WDS)
The WNDR3300 router can be used with a wireless access point (AP) to build large bridged
wireless networks. Wireless repeating is a type of Wireless Distribution System (WDS).
The following figure shows a wireless repeating scenario:
To set up a wireless network using WDS,
the following conditions must be met for both APs:
• Both APs must use the same SSID, wireless channel, and encryption mode (see “Manually
Configuring Your Wireless Settings” on page 2-4 or “Using Push 'N' Connect (WPS) to
Configure Your Wireless Network” on page 2-10).
• Both APs must be on the same LAN IP subnet. That is, all the AP LAN IP addresses are in the
same network.
Warning: If you use the wireless repeating function, your options for wireless security
are limited to None or WEP. For more information about wireless security, see
Chapter 2, “Safeguarding Your Network.”
Figure 5-10
Repeater APBase Station AP
