NETGEAR RangeMax WPNT511 User Manual

User Manual for the NETGEAR RangeMax™ 240 Wireless Notebook Adapter WPNT511
4-8 Network Connections and Wireless Security
v1.0, October 2005
You may need to reboot in certain Windows operating systems such as Windows 98SE.
Starting a Computer-to-Computer (Ad Hoc) Network Connection
1. On the Settings tab page of the Smart Wizard, select or type the Network Name (SSID).
2. Select the Computer-to-Computer (Ad Hoc) network type.
3. Click Initiate Ad Hoc. The Ad Hoc Setting dialog box opens:
4. In the Start Ad Hoc field, choose the wireless standard (2.4 GHz, 802.11b/g) for your Ad Hoc
computer-to-computer network.
5. In the Channel field, Automatic should work. If you notice interference problems with another
nearby wireless device, select a channel that is not being used by any other wireless networks
near your wireless adapter. Use the Networks tab page to identify the channels in use in your
area.
6. Click OK.
Note: If you cannot connect, see “Removing the WPNT511 Software” on page -12.
Also, for problems with accessing network resources, the Windows Client and
File and Print Sharing software might not be installed and configured properly
on your computers. Please see the link to “Internet Networking and TCP/IP
Addressing:” on page B-1.
Figure 4-7
Note: The channel number differs depending on the country. The connection speed
automatically defaults to the highest speed.

NETGEAR RangeMax WPNT511 Specifications

Frequency Range

frequency (US)	2.412 ~ 2.462 GHz
frequency (Japan)	2.412 ~ 2.472 GHz
frequency (Europe ETSI)	2.412 ~ 2.472 GHz

Wireless Speeds

wireless speeds	1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54, 72, 96, 108, 126, 240 Mbps
compatible standards	802.11b, 802.11g

Weight and Dimensions

dimensions	4.84 x 2.13 x .33 in (123 x 54 x 8.5 mm)
weight	1.9 oz (56g)
