NETGEAR RND2110v2 - Front and Side Panels

ReadyNAS Duo v2
11
ReadyNAS Duo v2 and NV+ v2
Front and Side Panels
The following figure shows the front and side panels of ReadyNAS Duo v2.
3
8
4 56
7
1
2
Figure 1. ReadyNAS Duo v2 front and side panels
1. Power button and LED
2. Disk activity LED
3. Exhaust vent
4. USB 2.0 port
5. Backup button
6. USB and backup status LED
7. Disk 1 and disk 2 LEDs
8. Drive bay door
