The following figure shows the front and side panels of ReadyNAS NV+ v2.
1
7
23 4 5 6
8
Figure 5. ReadyNAS NV+ v2 front and side panels
1. Exhaust vents
2. USB 2.0 port
3. Backup button and backup LED
4. Disk LEDs
5. Disk activity LED
6. Power button and LED
7. Drive bay door
8. Status display screen
