ReadyNAS NV+ v2
21
ReadyNAS Duo v2 and NV+ v2
The following figure shows a ReadyNAS NV+ v2 disk tray.
1
2
3
4
5
Figure 7. ReadyNAS NV+ v2 disk tray
1. Hard drive
2. Disk tray
3. Disk tray handle
4. Recessed disk tray locking mechanism
5. Disk tray release latch
