NETGEAR WAG511 User Guide

General SpecificationsTroubleshooting
Model WAG511 802.11a/b/g Wireless PC Card
802.11b Radio Data Rate 1, 2, 5.5, & 11 Mbps (Auto rate capable)
802.11g Radio Data Rate 6, 9, 12, 18, 24, 36, 48, 54 Mbps (Auto rate capable)
802.11b and 802.11g
Operating Frequency
2.412 ~ 2.462 GHz (US) 2.457 ~ 2.462 GHz (Spain)
2.412 ~ 2.484 GHz (Japan) 2.457 ~ 2.472 GHz (France)
2.412 ~ 2.472 GHz (Europe ETSI)
802.11b and 802.11g
Encryption
64-bit (also called 40-bit), 128-bit WEP data encryption
802.11a Radio Data Rate
6, 9, 12, 18, 24, 36, 48, 54 Mbps and 108 Mbps in turbo
mode (Auto rate capable)
802.11a Operating
Frequency
5.150 ~ 5.250 GHz (low band)
5.250 ~ 5.350 GHz (middle band)
5.725 ~ 5.825 GHz (high band)
802.11a Encryption 64-bit (also called 40-bit), 128-bit, 152-bit WEP data encryption
Bus Interface
32-bit CardBus
Provided Drivers
Microsoft Windows 98, Me, 2000, XP
Dimensions
Weight 1.6 oz (43.4 g)
FCC Part 15 Class B and Class E
Environmental Specifications Operating temperature: 32 to 140° F (0 to 60° C)
Operating humidity: 5-95%, noncondensing
Warranty Limited 3-year warranty
Electromagnetic Compliance
25
L: 4.76 in (121.2 mm)
W: 2.13 in (54 mm)
H: .45 in (11.4 mm)
The two LED’s
are blinking
alternately.
The Wireless PC Card is
not associated to any Access
Point properly. You may
not have configured the
wireless parameters of the
wireless nodes to be the
same as the Access Point.
• The Access Point may not be powered on.
• The Access Point and the WAB501 Wireless
PC Card are not configured with the same
wireless parameters. Check the SSID, turbo
mode option, and WEP encryption settings.
• The Access Point may be out of range. Try
moving the system closer to the Access Point
or readjusting the antenna on the Access
Point. You may also move the Access Point
to a higher location for better signal
reception by the Wireless PC Card.
I am associated
and connected to
an Access Point,
but I cannot see
the other
computers on
the Ethernet side
of the network.
This could be a physical
layer problem or a network
configuration problem.
• Check to make sure that the Access Point is
physically connected to the Ethernet network.
• Make sure that the IP addresses and the
Windows networking parameters are all
configured correctly.
Problem Cause Solution
No lights are lit
on the Wireless
PC Card.
The wireless card is not
inserted into the CardBus
slot on your PC properly or
the proper WAG511
Wireless PC Card driver is
not loaded.
• Remove and reinsert the Wireless PC Card.
• Check the device manager in Windows to
see if the adapter card is properly
recognized in the Windows operating
system. Reload the driver if necessary.
• Try to install the Wireless PC Card in
different CardBus slot if it’s available.
24
