Unpack the access point
The package contains the following items:
•
NETGEAR WAX630E access point
•
Mounting plate
•
Metal bracket with T-bar, lock screw, and 4 short screws
•
3 tall screws and anchors for wall mounting
•
Installation guide
Note: Model WAX630E ships without a power adapter. Model WAX630EP ships with
a power adapter (the type of power adapter varies by region). If you ordered model
WAX630E but prefer to use the access point without a PoE++ connection, you can order
a power adapter separately.
For information about the mounting options, see Mount the Access Point to a Wall or
Ceiling on page 261.
Top panel with LEDs
The LEDs that provide the status of the access point are located on the top panel of the
access point.
Figure 1. Top panel with LEDs
User Manual13Hardware Overview
Insight Managed WiFi 6E AXE7800 Tri-band Multi-Gig Access Point Model WAX630E
