NETGEAR WGR614 v4 User Manual

Reference Manual for the 54 Mbps Wireless Router WGR614 v4
2-4 Connecting the Router to the Internet
December 2003
Connecting the WGR614 v4
This section provides instructions for connecting the WGR614 v4 router. Also, the NETGEAR 54
Mbps Wireless Router WGR614 v4 Resource CD included with your router contains an animated
Installation Assistant to help you through this procedure.
Connecting the Router
There are three steps to connecting your router:
1. Connect the router to your network
2. Log in to the router
3. Connect to the Internet
Follow the steps below to connect your router to your network. You can also refer to the GearBox
CD for Cable/DSL Wireless Router WGR614 included with your router which contains an
animated Installation Assistant to help you through this procedure.
1. Connect the router to your network.
a. Turn off your computer and Cable or DSL Modem.
b. Disconnect the Ethernet cable (A) from your computer which connects to your cable or
DSL modem.
Figure 2-1: Disconnect the cable or DSL Modem
c.
Connect the Ethernet cable from your cable or DSL modem to the Internet port (A) on the
WGR614 v4.
Cable or DSL modem
A

NETGEAR WGR614 v4 Specifications

General

Wireless Protocol	802.11g
Frequency Band	2.4 GHz
Wireless Speed	54 Mbps
Security	WEP, WPA, WPA2
Antennas	1 external
Ports	4 LAN ports, 1 WAN port
WAN Port Type	Ethernet (RJ-45)
LAN Port Type	Ethernet (RJ-45)
Firewall	NAT, SPI
Weight	0.66 lbs
