Advanced Configuration 6-1
December 2003
Chapter 6
Advanced Configuration
This chapter describes how to configure the advanced features of your 54 Mbps Wireless Router
WGR614 v4. These features can be found under the Advanced heading in the Main Menu of the
browser interface.
Configuring Port Forwarding to Local Servers
Although the router causes your entire local network to appear as a single machine to the Internet,
you can make a local server (for example, a web server or game server) visible and available to the
Internet. This is done using the Port Forwarding menu. From the Main Menu of the browser
interface, under Advanced, click on Port Forwarding to view the port forwarding menu, shown
below.
Figure 6-1: Port Forwarding Menu
.
Note: If you are unfamiliar with networking and routing, refer to Appendix B,
“Network, Routing, Firewall, and Basics,” to become more familiar with the terms and
procedures used in this manual.
