NETGEAR WGR614 v6 User Manual

Reference Manual for the 54 Mbps Wireless Router WGR614 v6
P reparing Your N etwork C-5
202-10099-01, April 2005
You must have an Ethernet adapter, the TCP/IP protocol, and Client for Microsoft Networks.
If you need to install a new adapter, follow these steps:
a. Click the Add button.
b. Select Adapter, and then click Add.
c. Select the manufacturer and model of your Ethernet adapter, and then click OK.
If you need TCP/IP:
a. Click the Add button.
b. Select Protocol, and then click Add.
c. Select Microsoft.
d. Select TCP/IP, and then click OK.
Note: It is not necessary to remove any other network components shown in the
Network window in order to install the adapter, TCP/IP, or Client for Microsoft
Networks.

NETGEAR WGR614 v6 Specifications

General

Model	WGR614 v6
Category	Wireless Router
Wireless Standard	802.11g
Wireless Speed	54 Mbps
Frequency Band	2.4 GHz
LAN Ports	4 x 10/100 Mbps
WAN Port	1 x 10/100 Mbps
Security	WEP, WPA, WPA2
Firewall	NAT
Weight	0.66 lbs
