Reference Manual for the 54 Mbps Wireless Router WGR614 v6
M aintenance 5-5
202-10099-01, April 2005
Viewing a List of Attached Devices
The Attached Devices menu contains a table of all IP devices that the router has discovered on the
local network. From the Main Menu of the browser interface, under the Maintenance heading,
select Attached Devices to view the table, shown below.
Figure 5-4: Attached Devices menu
For each device, the table shows the IP address, NetBIOS Host Name (if available), and Ethernet
MAC address. Note that if the router is rebooted, the table data is lost until the router rediscovers
the devices. To force the router to look for attached devices, click the Refresh button.
Configuration File Management
The configuration settings of the WGR614 v6 router are stored within the router in a configuration
file. This file can be saved (backed up) to a user’s PC, retrieved (restored) from the user’s PC, or
cleared to factory default settings.
Rx B/s The current reception (inbound) bandwidth used on the WAN and LAN ports.
U p Time The amount of time since the router was last restarted.
U p T im e T h e tim e e la p se d s in ce th is p ort a cqu ired th e lin k.
P oll Interval Specifies the intervals at which the statistics are updated in this window. C lick on Stop
to freeze the display.
S e t I n terval E n te r a tim e a n d click th e b u tton to set th e p ollin g fre qu en cy.
S top C lick th e S top b u tton to fre e ze th e p ollin g in form a tion .
Table 5-3: Router Statistics Items (continued)
Item Description
