NETGEAR WGR614 v6 User Manual

Reference Manual for the 54 Mbps Wireless Router WGR614 v6
C-14 Preparing Your Network
202-10099-01, April 2005
• With Internet Protocol (TCP/IP) selected,
click on Properties to open the Internet
Protocol (TCP/IP) Properties dialogue box.
• Verify that
• Obtain an IP address automatically is
selected.
• Obtain DNS server address
automatically is selected.
• Click OK to return to Local Area
Connection Properties.
• Click OK again to complete the
configuration process for Windows 2000.
Restart the PC.
Repeat these steps for each PC with this version
of Windows on your network.

NETGEAR WGR614 v6 Specifications

General

Model	WGR614 v6
Category	Wireless Router
Wireless Standard	802.11g
Wireless Speed	54 Mbps
Frequency Band	2.4 GHz
LAN Ports	4 x 10/100 Mbps
WAN Port	1 x 10/100 Mbps
Security	WEP, WPA, WPA2
Firewall	NAT
Weight	0.66 lbs
