Reference Manual for the 108 Mbps Wireless Media Router WGT634U
3-4 Connecting the Router to the Internet
April 2004, 202-10018-02
First, Connect the WGT634U to the Internet
Follow the steps below to connect your WGT634U to the Internet.
1. CONNECT THE WIRELESS ROUTER BETWEEN YOUR COMPUTER & MODEM
a. Turn off your computer and broadband modem (cable or DSL).
b. Disconnect the Ethernet cable from your computer (point A in the diagram below).
Figure 3-1: Disconnect the Ethernet cable from your computer
c.
Securely insert the Ethernet cable into the Internet port (B) on the WGT634U. Your cable
or DSM modem is now connected directly to the WAN port of the WGT634U Wireless
Media Router.
Figure 3-2: Connect the Ethernet cable to the router
Broadband modem
A
Broadband modem
B
Internet Port
