NETGEAR WNA3100M User Manual

Set Up Your Wireless Adapter
10
NETGEAR N300 Wireless Mini USB Adapter WNA3100M
Join a Network or Connect to a Different Network
You can use WPS to join a wireless network if your wireless network supports it, or you can
join a wireless network from this NETGEAR Genie screen.
• WPS. Press and hold the WPS button on the side of the adapter for 2 seconds. Then
within 2 minutes, press the WPS button on your wireless router or gateway.
• NETGEAR Genie: Click your wireless network to select it from the list, and then click
Connect. If the network is secure, enter its password or network key.
After the adapter joins the network, it automatically saves the network connection information
to a Windows profile. Windows profiles can be used by Genie and the Windows utility. The
next time you launch NETGEAR Genie, it will automatically connect to the network you
previously joined if there's no change in the network information.
 To use WPS to join a wireless network:
1. Press and hold the WPS button on the side of the adapter for 2 seconds.
2. Then within 2 minutes, press the WPS button on your wireless router or gateway
The adapter joins the network, which can take a few minutes. Your settings are saved in a
profile.
Downloaded from www.vandenborre.be

NETGEAR WNA3100M Specifications

General

Interface	WLAN
Connectivity technology	Wireless
Ethernet LAN (RJ-45) ports	0
Chipset	-
Internal	No
Product color	Black
Wi-Fi band	Single-band (2.4 GHz)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Compatible operating systems	Microsoft Windows 7, XP, Vista: (32/64-bit)
Windows operating systems supported	Yes

Weight and Dimensions

Depth	34 mm
Width	16 mm
Height	8 mm
Weight	4 g
