Hardware Setup

N600 Wireless Dual Band Router WNDR3400v3

Hardware Features

Before you cable your router, take a moment to become familiar with the label and the front

and back panels. Pay particular attention to the LEDs on the front panel.

Front Panel

The router front panel has the status LEDs and icons shown in the following figure.

USB LED

WPS button

LAN Ports 1-4 LEDs

5 GHz LED

2.4 GHz LED

Internet LED

Power/Test LED

Table 1. Front panel LED descriptions

LED Description

USB

• Solid green. The local Ethernet ports have detected wired links with PCs.

• Blinking green. Data is being transmitted or received.

• Off. No link is detected on these ports.

NETGEAR WNDR3400v3 User Manual
