NETGEAR Wireless-N 300 Router WNR2000v2 User Manual
Customizing Your Network Settings 4-16
v1.0, January 2010
The following figure shows a wireless repeating scenario:
In the scenario shown, the following conditions must be met for both APs:
•
Both APs must use the same SSID, wireless channel, authentication mode (if any), and
encryption mode (see information about WEP in “Configuring WEP Wireless Security” on
page 2-9”).
•
Both APs must be on the same LAN IP subnet. That is, all the AP LAN IP addresses are in the
same network.
•
All LAN devices (wired and wireless computers) must be configured to operate in the same
LAN network address range as the APs.
•
If you are using DHCP, the Get Dynamically From ISP Gateway radio button in the Internet
IP Address section of the Basic Settings screen should be selected for all AP devices in the IP
Address Source section.
Figure 4-9
Wireless Router WNR2000 (AP 1) is in Wireless Base Station mode.
Internet
PCs
This wireless computer is
associated with AP 2.
This wireless computer is
associated with AP 1.
Modem
AP 2 is in
Repeater mode.
To Next Page
