NETGEAR WPN111 User Manual

User Manual for the NETGEAR RangeMax™ Wireless USB 2.0 Adapter WPN111
C -8 P rep aring Y ou r P C s for N etwork A ccess
202-10076-01
Now you should be at the Local Area
Network Connection Status window. This
box displays the connection status,
duration, speed, and activity statistics.
Administrator logon access rights are
needed to use this window.
• Click the Properties button to view
details about the connection.
The TCP/IP details are presented on the
Support tab page.
• Select Internet Protocol, and click
Properties to view the configuration
information.

NETGEAR WPN111 Specifications

Wireless Specifications

wireless speeds	1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54, 108 Mbps
frequency (US)	2.412 ~ 2.462 GHz
frequency (Japan)	2.412 ~ 2.472 GHz
frequency (Europe ETSI)	2.412 ~ 2.472 GHz
frequency (Spain)	2.457 ~ 2.462 GHz
frequency (France)	2.457 ~ 2.472 GHz

Physical Specifications

dimensions	94.5 x 30.2 x 15.2 mm
weight	32 g
