Netis E1+ User Manual

netis Wireless N Range Extender Quick Installation Guide
WPS
Step 1. Press the WPS Button on your main router.
Step 2. Press WPS Button on E1+ for 1～2 seconds.
WPS
WPS
Step 3. You are successfully connected!
WPS
Note: Once the setting is finished, the extended Wi-Fi will use the same
network name and password as your main router, then the wireless
devices can be connected to the Internet.
Also, you can connect a wired device like desktop, set-top box, printer to
E1+ with an Ethernet cable for network sharing.
4

Netis E1+ Specifications

General

Wireless Standard	IEEE 802.11b/g/n
Frequency	2.4GHz
Data Rate	Up to 300Mbps
Ports	1x 10/100Mbps Ethernet Port
Operating Temperature	0°C~40°C
Storage Temperature	-40°C~70°C
Operating Humidity	10%~90% non-condensing
Storage Humidity	5%~90% non-condensing
Antenna	2 x external antennas
Button	Reset
LED Indicator	Power
