150/300Mbps Wireless-N Long Distance Broadband RouterUser Manual
11
Click on ‘System management’- ‘Restore’, and click on the ‘Restore’ button.
2.4. Hardware Installation Procedures
The procedures to install the 150/300Mbps Wireless-N Long Distance Broadband
Routerpleaserefers to the following picture
WF2501
WF2502
Figure 2-3
 Attach one end of an Ethernet cable to your computer’s Ethernet port, and the other end to
one of the LAN ports of your router.
 Connect another Ethernet cable from your Cable/DSL modem to the WAN port of your
router.
 Connect the single DC output connector of the power adapter to the power jack on the back
of the router and plug the Power Adapter into an AC outlet.
