Press Apply to complete this operation and close the window.
3.2. Checking Connection with the Router
After configuring the TCP/IP protocol, use the ping command to verify if the computer
cancommunicate with the Router. To execute the ping command, open the DOS window
andPing the IP address of the 150/300MbpsWireless-N Long Distance Broadband Router at the
DOS prompt:
For Windows 98/Me: Start -> Run. Type command and click OK.
For Windows 2000/XP: Start -> Run. Type cmd and click OK.
For Windows Vista/7:Start→ Type cmd at the start search bar and press the Enter.
For MAC OS→Thesystem will complete this operation automatically.
At the DOS prompt, type the following command:
If the Command window returns something similar to the following:
C:\Documents and Settings\admin>ping 192.168.1.1
Pinging 192.168.1.1 with 32 bytes of data:
Reply from 192.168.1.1: bytes=32 time=1ms TTL=64
Reply from 192.168.1.1: bytes=32 time=1ms TTL=64
Reply from 192.168.1.1: bytes=32 time=1ms TTL=64
Reply from 192.168.1.1: bytes=32 time=1ms TTL=64
Ping statistics for 192.168.1.1:
Packets: Sent = 4, Received = 4, Lost = 0 (0% loss),
Approximate round trip times in milli-seconds:
Minimum = 1ms, Maximum = 1ms, Average = 1ms
Then the connection between the router and your computer has been successfully established.
If the computer fails to connect to the router, the Command window will return the following:
C:\Documents and Settings\admin>ping 192.168.1.1
Pinging 192.168.1.1 with 32 bytes of data:
