NetPing Uniping server solution v3/SMS - H2 O Leakage Sensor; Leakage Sensors, Model 2605

[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Sensors Plugin
[USS] Sensors Plugin
              –
Sensor Flex UniPing server solution v4/SMS,UniPingserver solution v3 Terminal Block
First wire One of IO lines – 1 - 8
Second Wire GND
A maximum allowable loop length is 100 meters.
H2O Leakage Sensor
A leakage sensor is plugged by a four-line wire according to the table:
Sensor Flex UniPing server solution v4/SMS,UniPingserver solution v3 Terminal Block
Green One of IO lines – 1 - 8
Yellow GND
Brown +5V
White GND
A sensor is packaged with an inseparable cable, withconnectors on the ends. A cable length can be increased with
the help offlat cable extenders of RC-4sensor, which are sequentially plugged one into another. Or it can be done
independently with the help of any wire with a minimum cross section of 0,4 mm
2
. Maximum allowable length of a
flat cable is 100 m.
Leakage Sensors, model 2605
A leakage sensor is plugged by a four-line wire according to the table:
Important! Sensors of a dry contact type, a supply voltage sensor, a leakage sensor, and others are plugged to
IOlines of a device. You can plug any eight sensors out of this set.
Important! A corresponding IOline should be set to an input mode in settings of a device.
Important! Sensors of a dry contact type, a supply voltage sensor, a leakage sensor, and others are plugged to
IOlines of a device. You can plug up to eight sensors of this set.
Important! A correspondent IOline should be set to an input mode in settings of a device.
