NV-202 VDSL2 Bridge with DIP Switch USER’S MANUAL Ver. A4
25
1 x DIP Switch
1 x Power Jack
Cable Connections:
RJ-45 (Ethernet): Category 3~7 UTP/STP
RJ-11 (VDSL2): Twisted Pair phone wire
LED Indicators:
1 x Power LED
2 x Link/Active Status for Ethernet port
1 x Link LED for VDSL2 port
1 x CO Mode indicator LED
1 x CPE Mode indicator LED
VDSL2 Line Code:
Discrete multitone (DMT) modulation
VDSL 2Transmission Mode:
Packet Transfer Mode (PTM)
Typical Power Consumption:
5 W
Power Requirement:
Input Voltage: 12VDC / 1A (Commercial-grade Power Adapter)
EMC:
EMI Compliant: FCC class B
EMS Compliant: CE mark
Operating Temperature:
0°C ~ 50°C (32°F ~ 122°F)
Fanless, free air cooling
Storage Temperature:
-20°C ~ 70°C (-4°F ~158°F)
Humidity:
10% to 90% (non-condensing)
Weight:
About 0.34 kg
Dimensions:
95 x 110 x 27 mm ( 3.74" x 4.33" x 1.06”)
