Log Event Codes
View System Log
Theengineercanusethisoptiontoviewthesystem
log. The [A] and [C] keys allow you to scroll
backwards and forwards through the log events.
Configure Wards
Enter CCT No.>--
Office PIR
CCT 01 in [ ]
Circuit text
Enter circuit No.
e.g. 01
e.g. Press A & B
Wards
= Assign to ward A
8
ENT
A
= Assign to ward B
B
= Assign to ward C
C
Engineers menu 2
Select Option :-
Office PIR
CCT 01 in [AB ]
StarburstLCD
LED
E2 -
ENGR 2 -
01-
CCT 01 -
01-
CCT 01-
01-A
01-B
CCT 01-A
CCT 01-B
---
---
Configure Wards Flowchart
PASSCODE 01
08:40.59 28/04
to alternate
Name &
User No.
Date/Time
Event type
= Scroll backwards
9
ESC
A
B
= Scroll forwards
C
Engineers menu 2
Select Option :-
ALARM 02
08:45.59 28/04
to alternate
Circuit No. &
Circuit Text
Date/Time
Event type
= Scroll backwards
A
B
= Scroll forwards
C
View System Log Flowchart
LCD Starburst LED Description
ACTION ALARM
ALM SENT
AA
Bell output activated when system is part-set.
AC OFF
A.C. OFF
PF
Mains power removed.
AC RESTORED
A.C. ON
Pr
Mains power restored
ACCESS 01-31
ACC’SS 01-31
Ac. 01-31
Access user passcode (01-31) entered.
ALARM 01-56
ALARM 01-56
CA. 01-56
Full alarm from circuit (01-56).
ALARM DELAYED 01-56
DELAY 01-56
AD. 01-56
Delayed alarm during a part-set condition.
AUX/BELL TAMPER
AUX TAMP
AT
Auxiliary tamper activated.
AUXILIARY 01-56
AUX 01-56
Au. 01-56
Auxiliary circuit activated.
BATTERYFAULT
BATT FLT
BF
Battery fault (voltage below 10.5V).
BELLTESTED
BELL TST
BT
External bell and strobes tested.
CALLBACKNo.01-03
C. BACK 01-03
CB. 01-03
Modem making a call back to remote PC.
CCTS ISOLATED
24HR OM’T
CI
24Hr group omitted during the unset condition.
CCT OMITTED
OMIT’D 01-56
CO. 01-56
Circuits omitted by the user at time of Setting.
CIRCUITSTESTED 01-56
TEST’D 01-56
Tc. 01-56
The number of circuits tested during Walk Test.
CODETAMPER
C.TMP 01-04
PT. 01-04
Code tamper from keypad 01-04
COMMS ACTIVE
COM ACT
cA
Plug-on digicom active.
COMMS FAILED
COMS FLT
cF
Plug-on digicom failed to communicate.
COMMS SUCCESSFUL
COMS OK
cc
Plug-on digicom communicated successfully.
Engineer's Menu 2 TS900 Installation Manual
