Table of contents
1 INTRODUCTION 3
1.1 Receiving Inspection 3
1.2 Certification 3
2 GENERAL SAFETY REGULATIONS 3
2.1 Additional General Safety Regulations for
Atmos Heating 4
2.2 Disposal 4
2.3 California Proposition 65 Warning 4
3 ASSEMBLY OF THE FIREPLACE 5
3.1 Required Tools 5
3.2 Included Hardware 5
3.3 Removal of Covers 5
3.4 Adjustable Feet 5
3.5 Rear Screen Assembly 5
3.6 Top Screen Assembly 7
4 INSTALLING THE FIREPLACE 8
4.1 Light / Illumination 8
4.2 Viewing Height 8
4.3 Connecting Fireplace to Power 8
4.4 Ventilation Openings 8
4.5 Framing Dimensions 8
4.6 Wall Dimensions 9
4.7 Fireplace Finishing in Combination With
Atmos Heating 9
5 SETTING UP THE FIREPLACE 10
5.1 Flat Bottom Plate 10
5.2 (Optional) Placing Design Bottom Plates 10
5.3 Installing Side Cover Plates 10
5.4 Installing Side L-Brackets 10
5.5 Log Set Installation 11
5.6 Placing Glass Reflector 13
5.7 Placing Post Covers 13
5.8 Placing Side Window 13
5.9 Placing Front Window 14
5.10 Front Window Adjustment 14
6 E-ONE OPERATION 15
6.1 Main On/Off Switch 15
6.2 Hotel Switch 15
6.3 Remote Control Pairing 15
6.4 E-One Remote and Symbols 16
7 MAINTENANCE 17
7.1 Cleaning The Fireplace 17
7.2 Cleaning The Glass Reflector 17
8 WARRANTY 18
9 TECHNICAL DATA 18
9.1 Specifications 18
9.2 Serial Number Label 18
9.3 Wire Diagram 19
9.4 Dimension Drawing 19
