MPCX2 TENNIS CONTROL (front view)
LCD Display (16 characters x 2 lines)
Selects the SET number
and
Puts the control into scoring mode
OPTIONS key
Allows you to:
Clear Data for ALL Courts
Clear Data for active court
Set Brightness of Scoreboard
Check Battery Level
Check Signal Strength
Link Control to Receiver Network
Select Scoreboard Model Type
Change the Active Court
Selects the HOME or GUESTS
(for scoring)
Add to or Subtract from selected
feature
Selects the TOTAL scores on
scoreboard
MPCX2 Six Court TENNIS Control System
MPCX2 TENNIS CONTROL (rear view)
Battery
Compartment
Cover
(2 x AA)
The Nevco six court Tennis control system consists of one receiver and six hand-held controls. Each control can
post information on the scoreboard for the court it has been assigned to.
