Neve 88M - Detailed Audio Specifications; DI Inputs; Insert Sends; Monitor Outputs

18
DI Inputs
Frequency Response
20Hz to 20kHz
+/- 0.1dB
Frequency Response
10Hz to 35kHz
+/- 0.5dB
Dynamic Range
>100dB
Distortion (THD+N)
<0.006%
Gain Range
+13 to +60dB
Maximum Input Level
(Max Gain @ 60dB)
-42dBu
Maximum Input Level
(Min Gain @ 13dB)
+5dBu
Input Impedance
≈900kΩ
Insert Sends
Maximum Output Level
18dBu (Balanced TRS)
Dynamic Range
>112dB
Mon Outputs
Maximum Output Level
18dBu (Balanced TRS)
Dynamic Range
>113dB
Headphone output (150 Ohm load)
Maximum Output Level
10dBu
Frequency Response
20-20kHz +/- 0.3dB
Distortion (THD +N)
<0.007% @10dBu 1kHz
Noise floor
-96dBA
Metering
Signal
-43dBFS
Clip
-3dBFS
Crosstalk
Inter-channel crosstalk
<-60dBr @ 10kHz
