Neve 88M - Unit Connection Tables; ¼ Inputs and Outputs; XLR Inputs & Outputs

20
Unit Connection Tables 1
Power and Comms
USB3 Type-B
Preamplifier Microphone Inputs
XLR 3-pin plug female
Preamplifier Line Inputs
¼" TRS Jack sockets
Preamplifier DI inputs
¼" TRS Jack sockets
Headphone Output
¼" TRS Jack socket
Insert Sends
¼" TRS Jack sockets
Insert Returns
¼" TRS Jack sockets
Monitor Outputs
¼" TRS Jack sockets
¼“ Inputs and Outputs
All ¼’’ Line Inputs & Outputs on the unit have the same wiring, excluding headphones
Tip
Hot
Ring
Cold
Sleeve
Ground
XLR Inputs & Outputs
All XLR Inputs & Outputs on the unit have the same wiring
Pin 2
Hot
Pin 3
Cold
Pin 1
Ground
