Audio Specification 1
General Specifications
Headroom
+18dBu @ 1kHz (<0.5% THD+N)
Distortion (THD+N)
Typically 0.008% @ 1kHz (measured at +18dBu, 10Hz to 80kHz filter)
General Noise
<-85dBu (A-wtg)
Microphone Inputs
Frequency Response
20Hz to 20kHz
+/- 0.1dB
Frequency Response
10Hz to 35kHz
+/- 0.5dB
Dynamic Range
>110dB
Distortion (THD+N)
<0.004%
Noise EIN
-125dBA
Gain Range
+21dB to +68dB
Maximum Input Level
(Max Gain @ 68dB)
-50dBu
Maximum Input Level
(Min Gain @ 21dB)
-3dBu
Input Impedance
≈1.5kΩ
Line Inputs
Frequency Response
20Hz to 20kHz
+/- 0.1dB
Frequency Response
10Hz to 35kHz
+/- 0.5dB
Dynamic Range
>111dB
Distortion (THD+N)
<0.006%
Gain Range
-12dB to +35dB
Maximum Input Level
(Max Gain @ 35dB)
-17dBu
Maximum Input Level
(Min Gain @ -12dB)
+30dBu
Input Impedance
≈20kΩ
