Introduction LB1005 Operating Manual
2 Revision 1 Bookham
Parts List
The LB1005 is shipped in a package designed to provide excellent protection. The
shipping box should be saved for future transportation or storage needs.
Carefully remove and inspect the following items that are contained in the
shipping box:
• LB1005 Servo Controller
• LB1005 Operating Manual
• AC Power Cord
Electrical Fuse & Voltage Selection
The LB1005 is pre-configured at the factory to work with the AC mains voltages
for your region. Before supplying electrical power to the LB1005, confirm that
the power entry module located on the rear panel is installed with the proper
fuses and set to the correct wallplug AC voltage. Use Table 1 to determine the
appropriate fuse and voltage settings.
Table 1: Fuse & Voltage Settings
AC Mains*
V~
Tolerance
V~
Fuse Rating**
Module Voltage
Wheel Setting
100 90—110 100Vac
120 108—132
250 V
0.50 A T
120Vac
220 198—242 220Vac
230-240 207—264
250 V
0.25 A T
240Vac
* 50/60 Hz only. **Module only accepts dual metric 5 x 20 mm fuses.
To operate at another AC mains voltage, follow the procedure below:
• With a small screwdriver, pry open fuse cover of the power entry module on
rear panel. The AC power cord must be removed from module socket before
opening fuse cover.
• Carefully pull out the voltage selection wheel from the module. Re-insert so
that correct AC voltage setting is facing outwards.
• Pull out the two fuse holders located below voltage selection wheel. Insert
correct fuses into each fuse holder and re-insert back into module. Install fuse
holders so that arrows on fuse cover and fuse holder align.
• Snap fuse cover back into place. Verify that the correct AC mains voltage can
be read through fuse panel before attaching the AC power cord.
