Newmac LFR-80V - Nh3 General Instructions

1
TABLE 1
NH3 GENERAL INSTRUCTIONS
UPFLOW CONFIGURATION
BURNER AIR SETTING DIRECT DRIVE SPEED TAP BELT DRIVE
MODEL
RIELLO
BURNER
B.T.U.H.
OUTPUT
B.T.U.H.
INPUT
(USGPH)
AFUE
%
NOZZLE
PUMP
p.s.i.
INSERTION
inches
TURB SHUTTER
CHIMNEY
FLUE
PRESSURE
(in w.c.)
GROSS
STACK
°F
FILTER SIZE
(QTY)
12”
BLOWER
10”
BLOWER
9”
BLOWER
PULLEY
COMBINATION
TURNS
OPEN
EXTERNAL
STATIC
PRESSURE
(in w.c.)
MED-HI MED-HI MED-HI
NH3 – 122 40 F3 122,000
144,976
(1.04)
81.1
Delavan 0.85 X 60° B
Monarch 0.85 X 60° R
150 4 5/8” 3 4.0 -0.02 500 16” X 24” (2)
MED-HI MED-HI MED-HI
MED MED-LO MED-HI 3-1/4” X 6” 1 – 1/2 0.20
NH3 – 109 40 F3 109,000
128,248
(0.92)
81.5
Delavan 0.75 X 60° B
Monarch 0.75 X 60° R
150 4 5/8” 3 3.1 -0.02 460 16” X 24” (2)
MED MED-LO MED-HI 3-1/4” X 5” 1 0.50
MED-LO MED-LO MED-LO 3-1/4” X 6” 2-1/2 0.20
NH3 – 95 40 F3 95,000
111,520
(0.80)
82.2
Delavan 0.65 X 60° B
Monarch 0.65 X 60° R
150 4 5/8” 2 2.7 -0.02 425 16” x 24” (2)
MED MED-LO MED-HI 3-1/4” X 5” 2 0.50
MED-LO LO MED-LO 3-1/4” X 6” 3 0.20
NH3 – 90 40 F3 89,000
103,156
(0.74)
82.7
Delavan 0.60 X 60° B
Monarch 0.60 X 60° R
150 4 5/8’ 1.5 2.5 -0.02 400 16” X 24” (2)
MED LO MED-LO 3-1/4” X 5” 2-1/2 0.50
BURNER AIR SETTING DIRECT DRIVE SPEED TAP BELT DRIVE
MODEL
BECKETT
BURNER
B.T.U.H.
OUTPUT
B.T.U.H.
INPUT
(USGPH)
AFUE
%
NOZZLE
PUMP
p.s.i.
INSERTION
inches
SHUTTER AIR BAND
CHIMNEY
FLUE
PRESSURE
(in w.c.)
GROSS
STACK
°F
FILTER SIZE
(QTY)
12”
BLOWER
10”
BLOWER
9”
BLOWER
PULLEY
COMBINATION
TURNS
OPEN
EXTERNAL
STATIC
PRESSURE
(in w.c.)
MED-HI MED-LO MED-HI
NH3 – 117 AFG60YHHS 117,000
139,400
(1.00)
81.0
Delavan 1.00 X 70° A
Monarch 1.00 X 70° NS
100 5” 10 1 -0.02 515 16” X 24” (2)
MED-HI MED-HI MED-HI
MED MED-LO MED-LO 3-1/4” X 6” 3 0.20
NH3 – 101 AFG60YHHS 101,000
118,490
(0.85)
81.7
Delavan 0.85 X 70° A
Monarch 0.85 X 70° NS
100 5” 8 0 -0.02 475 16” X 24” (2)
MED MED-LO MED-LO 3-1/4” X 5” 2-1/2 0.50
MED MED-LO MED-LO 3-1/4” X 6” 3 0.20
NH3 – 89 AFG60YHHS 89,000
104,550
(0.75)
82.7
Delavan 0.75 X 70° A
Monarch 0.75 X 70° NS
100 5” 6 0 -0.02 450 16” X 24” (2)
MED MED-LO MED-LO 3-1/4” X 5” 2-1/2 0.50
MED-LO LO LO 3-1/4” X 6” 3 0.20
NH3 – 77 AFG60YHHS 77,000
90,610
(0.65)
82.5
Delavan 0.65 X 70° A
Monarch 0.65 X 70° NS
100 5” 5 0 -0.02 425 16” X 24” (2)
MED-LO LO LO 3-1/4 X 5” 2-1/2 0.50
DIRECT DRIVE SPEED TAP BELT DRIVE
MODEL
AERO
BURNER
B.T.U.H.
OUTPUT
B.T.U.H.
INPUT
(USGPH)
AFUE
%
NOZZLE
PUMP
p.s.i.
INSERTION
inches
BURNER AIR SETTING
AIR BAND
CHIMNEY
FLUE
PRESSURE
(in w.c.)
GROSS
STACK
°F
FILTER SIZE
(QTY)
12”
BLOWER
10”
BLOWER
9”
BLOWER
PULLEY
COMBINATION
TURNS
OPEN
EXTERNAL
STATIC
PRESSURE
(in w.c.)
MED MED-LO MED-LO 3-1/4” X 6” 3 0.20
NH3 – 100 HF-US-2X 101,000
118,490
(0.85)
81.7
Delavan 0.85 X 70° A
Monarch 0.85 X 70° NS
100 5” 7/16” -0.02 450 16” X 24” (2)
MED MED-LO MED-LO 3-1/4” X 5” 2-1/2 0.50
MED MED-LO MED-LO 3-1/4” X 6” 3 0.20
NH3 – 88 HF-US-2X 89,000
104,550
(0.75)
82.7
Delavan 0.75 X 70° A
Monarch 0.75 X 70° NS
100 5” 5/8” -0.02 425 16” X 24” (2)
MED MED-LO MED-LO 3-1/4” X 5” 2-1/2 0.50
MED-LO LO LO 3-1/4” X 6” 3 0.20
NH3 – 78 HF-US-2X 77,000
90,610
(0.65)
82.5
Delavan 0.65 X 70° A
Monarch 0.65 X 70° NS
100 5” 7/8” -0.02 400 16” X 24” (2)
MED-LO LO LO 3-1/4” X 5” 2-1/2 0.50
BURNER AIR SETTING DIRECT DRIVE SPEED TAP BELT DRIVE
MODEL
CARLIN
BURNER
B.T.U.H.
OUTPUT
B.T.U.H.
INPUT
(USGPH)
AFUE
%
NOZZLE
PUMP
p.s.i.
INSERTION
inches
POSITIONING
BAR
AIR BAND
CHIMNEY
FLUE
PRESSURE
(in w.c.)
GROSS
STACK
°F
FILTER SIZE
(QTY)
12”
BLOWER
10”
BLOWER
9”
BLOWER
PULLEY
COMBINATION
TURNS
OPEN
EXTERNAL
STATIC
PRESSURE
(in w.c.)
MED MED-LO MED-LO 3-1/4” X 6” 3 0.20
NH3 – 99 EZ-1 101,000
118,490
(0.85)
81.7
Delavan 0.85 X 70° A
Monarch 0.85 X 70° NS
100 5” 0.85-1.00 GPH 0.65 -0.02 450 16” X 24” (2)
MED MED-LO MED-LO 3-1/4” X 5” 2-1/2 0.50
MED MED-LO MED-LO 3-1/4” X 6” 3 0.20
NH3 – 87 EZ-1 89,000
104,550
(0.75)
82.7
Delavan 0.75 X 70° A
Monarch 0.75 X 70° NS
100 5” 0.75 GPH 0.60 -0.02 415 16” X 24” (2)
MED MED-LO MED-LO 3-1/4” X 5” 2-1/2 0.50
MED-LO LO LO 3-1/4” X 6” 3 0.20
NH3 – 76 EZ-1 77,000
90,610
(0.65)
82.5
Delavan 0.65 X 70° A
Monarch 0.65 X 70° NS
100 5” 0.60-0.65 GPH 0.50 -0.02 380 16” X 24” (2)
MED-LO LO LO 3-1/4” X 5” 2-1/2 0.50
Use burner air settings as a guide only. Set burner air to give a trace of smoke. Re-adjust burner air to reduce CO
2
by 1 to 1.5 percent. Take measurements with the burner cover & air ducts installed
(if any).
The maximum allowable temperature rise is 85°F. Select speed to suit specific installation requirements. Air temperature can be lowered by increasing the blower speed; lowering the firing rate; or
increasing supply & return outlets.
The minimum recommended temperature rise is 65°F.
