Newport 1917-R User Manual

11
Range down can be manually selected using the range down button..
6 - Digital high Control Keys
Displays the maximum recorded values. To return to measurement display mode,
press the key again.
7 - Digital low / W/dBm Control Keys
Displays the maximum recorded values. To return to measurement display mode,
press the key again.
The dBm function is available by pressing more than 2 seconds on the Digital-
Low control key. The Uno will convert the displayed number in dBm (dB
referenced to 1mW) and will display “dBm” message unit and then no units. To
get back to the previous display in Watt, press again more than 2 seconds on the
Zero control key. The ranges are also displayed in dBm.
8 - Display
Two parts digital/analog display LCD screen. Refer to section 2.2 for a detailed
description.
