Chapter 2: Jumpers and Connectors
DNA 1120/1120A User Manual
H/W Reset
Connector type: 1x2 2-pin header, 2.54mm-M-180
Connector location: JP5
Pin Description
1 ICH_SYS_RESET_N_R
2 GND
2
1
Power Type Select
Connector type: 2x2 dip switch
Connector location: SW2
SW2
Pin Definition Pin Definition
1 PWRBT_R# 2 GAL_AT#_ATX
3 GND 4 ICH_PWRBTN_N
