Chapter 2: Jumpers and Connectors
DNA 1120/1120A User Manual
Internal Connectors
SATAII Port
Connector type: Standard Serial ATAII, 1.27mm
Connector location: J1
Pin Definition
1 GND
2 TXP0
3 TXN0
4 GND
5 RXN0
6 RXP0
7 GND
1
7
SATAII Port
Connector type: Standard Serial ATAII, 1.27mm
Connector location: J3
Pin Definition
1 GND
2 TXP1
3 TXN1
4 GND
5 RXN1
6 RXP1
7 GND
1
7
