Chapter 3: System Setup
DNA 1120/1120A User Manual
Installing a PCI Card
2. Remove the mounting screws that secure the L-shaped bracket to the
chassis.
1. The PCI slot is attached on an L-shaped bracket.
L-shaped
bracket
Mounting
screw
