Nexcom DNA 1120 - PS;2 Keyboard;Mouse Connector; GAL Programming Connector

Copyright © 2011 NEXCOM International Co., Ltd. All Rights Reserved.
20
Chapter 2: Jumpers and Connectors
DNA 1120/1120A User Manual
PS/2 Keyboard/Mouse Connector
Connector type: 2x4 8-pin header, 2.54 mm
Connector location: J7
1
2
7
8
Pin Definition Pin Definition
1 VCC5 2 VCC5
3 KB_DATA 4 LM_DATA
5 KB_CLK 6 LM_CLK
7 GND 8 GND
GAL Programming Connector
Connector type: 1x6 6-pin header, 2.54 mm
Connector location: J8
6
1
Pin Definition
1 3VSB
2 GND
3 GAL_TCK_2
4 GAL_TDO_2
5 GAL_TDI_2
6 GAL_TMS_2
