Chapter 2: Jumpers and Connectors
DNA 1120/1120A User Manual
Digital I/O Connector
Connector type: 2x5 10-pin header, 2.0 mm pitch
Connector location: J4
1
2
9
10
Pin Definition Pin Definition
1 VCC5 2 GND
3 SIO_GPIN10 4 SIO_GPOUT14
5 SIO_GPIN11 6 SIO_GPOUT15
7 SIO_GPIN12 8 SIO_GPOUT16
9 SIO_GPIN13 10 SIO_GPOUT17
COM2 Connector (RS232)
Connector type: 2x5 10-pin boxed header, 2.0 mm
Connector location: CN8
1
2
9
10
Pin Definition Pin Definition
1 SP_DCD2 2 SP_RXD2
3 SP_TXD2 4 SP_DTR2
5 COM2_GND 6 SP_DSR2
7 SP_RTS2 8 SP_CTS2
9 SP_RI2 10 COM2_GND
