Chapter 3: System Setup
DNA 1120/1120A User Manual
Connector side of
the SATA drive
4. Turn to the other side of the bay then use the provided mounting
screws to secure the SATA drive to the drive bay.
Mounting screw
5. The photo below shows the screws mounted in place.
SATA drive located
underneath
