TDcontroller USER GUIDE
This section describes the Analogue TDcontroller PS8TD, PS10, and PS15MK2. For information
concerning the NX241 Digital TDcontroller, please refer to the NX241 Operating Manual.
Read before use
The PS TDcontroller is designed to be used with PS and LSub speaker cabinets. Its main functions are:
• To optimize the response of the system
• When operating with a Sub-bass system (optional), splitting the stereo (2 channel) signal into 2 frequency
bands (PS main system and LSub Sub-bass system)
• When operating in active configuration (PS15 only), splitting the mono (single channel) signal into 3
frequency bands (SUB, LF & HF)
• Active protection of the cabinets by dynamic audio signal processing (Temperature and Displacement
servo control)
• Reduction of amplifier overload (Peak limiter function)
PS TDcontrollers also feature:
• Stereo operation (2 independent channels) for the main system
• Global switchable output level according to amplifier gain
• Individual gain control for each channel (PS15 only)
• Adjustable level on the Sub-bass channel
• Balanced input and output stages (High CMRR input stage and High current drive output on PS15TD)
• User array LF EQ (PS15TD only)
• Enhanced protection facility for additional safety margin when the cabinet is subjected to extended periods
of overload.
• Fallback servo control mode prevents protection loss when sense lines are accidentally disconnected
