PS8, PS8TD & LS400 : SPECIFICATIONS, CURVES & DIAGRAMS
SYSTEM SPECIFICATIONS
PS8 with PS8 TDcontroller LSub 400 with PS8 TDcontroller
Frequency Response [a]
69 Hz - 19 kHz ±3dB 43 Hz - 120 Hz ±3dB
Usable Range @-6dB [a]
62 Hz – 20 kHz 40 Hz - 140 Hz
Sensitivity 1W @ 1m [b]
96 dB SPL Nominal - 94 dB SPL Wideband 99 dB SPL Nominal
Nominal Peak SPL @ 1m [b]
122 to 125dB Peak (for 200 to 500 W RMS Amp.) 128 to 131 dB Peak (300 to 700 W RMS Amp.)
HF Dispersion [c]
50° to 100° Hor. x 55° Vert. Rotatable Horn, 4 positions -
Directivity : Q & DI [c]
Q : 10 Nominal DI : 10 dB Nominal ( f > 1.8 kHz ) -
Crossover Frequencies
2.5 kHz Passive 120 Hz Active through PS8TD
Nominal Impedance
8 Ohms 6 Ohms
Recommended Amplifiers
200 to 500 Watts into 8 Ohms for 1 x PS8 per channel
400 to 1000 Watts into 4 Ohms for 2 x PS8 per channel
300 to 700 Watts into 4 Ohms
SYSTEM OPERATION
Electronic Controller
The PS8 TDcontroller is precisely matched to the PS8 & LS400 cabinets and includes sophisticated protection systems. Using
PS8 & LS400 without a properly connected PS8TD will result in poor sound quality and can damage the components. PS8 &
LS400 can also be used with the NX241 Digital TDcontroller.
Dispersion configuration
After quick-release of the front grille from its fixings, the HF Horn can be rotated in 4 positions for dispersion configuration.
Subbass
The PS8 can be used without optional LS400 Subbass. Active two-way operation with the LS400 is included in the PS8TD.
One LS400 matches 2 x PS8, additional LS400 may be used for enhanced effect.
Speaker Cables
PS8 are wired 2- & 2+ on Speakon connectors, LS400 on 1- & 1+. Loop through Speakons are present on both. Single
identical cables can thus be used to loop through combinations of up to 2 x PS8 & 1 x LS400 in no particular order.
PRODUCT FEATURES
PS8 LSub 400
Components : LF [VLF]
1 x 8" (20cm) Shielded Neodymium 8 Ohms driver 1 x 12" ( 30cm ) long excursion 6 Ohm driver
HF
1 x 1" Shielded Neodymium throat driver + Low Distorsion,
Constant Directivity Asymetrical Dispersion Horn.
-
Height x Width x Depth
406 x 250 x 219 mm (16"x 9 7/8"x 5 5/8") 338 x 500 x 406 mm (13 1/4’’x 19 5/8’’x 16")
Weight : Net
7.5 kg (16.5 Lb) 19.5 kg (43 Lb)
Connectors
2 x NL4MP SPEAKON 4 pole 2 x NL4MP SPEAKON 4 pole
Construction
Baltic Birch Ply finished with structured black coating Baltic Birch Ply & structured black coating
Fittings: Handles
- 2 Metal Handles
Front finish
Perforated steel grille -
Flying Points & Fixed Installation
Threaded inserts are fitted as standard to all cabinet surfaces for
connection of mounting accessories
-
Stand fittings
Built in Stand Fitting, 35mm (1"3/8) Internal Stand Fitting on Top (35mm, 1"3/8) accepts a
mast supporting 1 or 2 PS8's.
PRODUCT FEATURES
PS8 TDController
Audio Inputs
Two L&R Audio inputs. Electronically balanced, 36 kOhm. Two XLR-3F connectors.
Sense Inputs
Three Amplifier Sense Inputs (PS8 L&R, LS400). 150 kOhm. 6 Pole Removable Strip Terminal.
Audio Outputs
Two L&R PS8 Audio outputs. Electronically balanced, 50 Ohm. Two XLR-3M.
One Mono (L+R) LS400 Audio output. Electronically balanced, 50 Ohm. One XLR-3M.
Specifications
Output Level : +20 dBm Max. +19dBm Max on 1kOhm
Noise : -88 dBm (22 Hz - 22 kHz, UnWeighted). THD+N : < 0.03% Typ. 0.05 Max for +18dBm Output
Controls & Indicators
Std/Max Protection Trimmer. Gain switch (back panel), 3 positions for Amps with Gain : -12 / -6 / 0 dB.
Sub On switch & Sub Gain Control. Speaker Protect LED's. Amp Sense & Peak LED's.
Power Supply
110/220 Volts (internal wiring), 50/60Hz. Earth-Lift (back panel)
Dimensions & Weight
1U 19" Rack. 190mm (7.5") Depth. 2.9 kg (6.6 Lbs) net
