PS10, PS10TD & LS500 : SPECIFICATIONS, CURVES & DIAGRAMS
SYSTEM SPECIFICATIONS PS10 with PS10 TDcontroller LSub 500 with PS10 TDcontroller
Frequency Response [a] 65 Hz - 20 kHz ±3dB 40 Hz - 110 Hz ±3dB
Usable Range @-6dB [a] 58 Hz - 21 kHz 38Hz - 120 Hz
Sensitivity 1W @ 1m [b] 98 dB SPL Nominal - 96 dB SPL Wideband 101 dB SPL Nominal
Nominal Peak SPL @ 1m [b] 124 to 127 dB Peak (for 200 to 500 W RMS Amp.) 131 to 134 dB Peak (300 to 800 W RMS Amp.)
HF Dispersion [c] 50° to 100° Hor. x 55° Vert. Rotatable Horn, 4 positions -
Directivity : Q & DI [c] Q : 16 Nominal DI : 12 dB Nominal ( f > 3 kHz ) -
Crossover Frequencies 2 kHz Passive 120 Hz Active through PS10 TD
Nominal Impedance 8 Ohms 4 Ohms
Recommended Amplifiers 200 to 500 Watts into 8 Ohms for 1 x PS10 per channel 400
to 1000 Watts into 4 Ohms for 2 x PS10 per channel
300 to 800 Watts into 4 Ohms
SYSTEM OPERATION
Electronic Controller The PS10 TDController is precisely matched to the PS10 & LS500 cabinets and includes sophisticated protection
systems. Using PS10 & LS500 without a properly connected PS10 TD will result in poor sound quality and can
damage the components.
Dispersion configuration After quick-release of the front grille from its fixings, the HF Horn can be rotated in 4 positions for dispersion
configuration.
Subbass The PS10 can be used without optional LS500 Subbass. Active two-way operation with the LS500 is included in
the PS10 TD. One LS500 matches 2 x PS10, additional LS500 may be used for enhanced effect.
Speaker Cables PS10 are wired 2- & 2+ on Speakon connectors, LS500 on 1- & 1+. Loop through Speakons are present on both.
Single identical cables can thus be used to loop through combinations of up to 2 x PS10 & 1 x LS500 in no
particular order.
PRODUCT FEATURES PS10 LSub 500
Components : LF [VLF] 1 x 10" (25cm) 8 Ohm driver 1 x 15" (38cm) long excursion 4 Ohm driver
HF 1 x 1" throat driver + Low Distorsion,
Constant Directivity Asymetrical Dispersion Horn.
-
Height x Width x Depth 515 x 316 x 277 mm (20.28"x 12.44"x 10.91") 430 x 689 x 528 mm (16.93"x 27.13"x 20.79")
Weight : Net 15 kg (33 Lbs) 33 kg (73 Lbs)
Connectors 2 x NL4MP Speakon 4 pole 2 x NL4MP Speakon 4 pole
Construction Baltic Birch Ply finished with structured black coating Baltic Birch Ply & structured black coating
Fittings: Handles 2 Metal recessed pockets 2 Metal recessed pockets
Front finish Acoustic foam on hex perforated steel grille (77% transparent) Perforated steel grilles
Flying Points 1 steel anchor plate for flying track on top (6 positions).
2 steel anchor plates for flying tracks on bottom (1 position)
3 steel anchor plates for flying
tracks on sides and back
Stand fittings Built in Steel Stand Fitting, 35mm (1"3/8) Internal Steel Stand Fitting on Top (35mm,
1"3/8) accepts a mast supporting 1 or 2 PS10's.
Fixed Installation Two sets of 4 fixing points (Omnimount 100 Std spacing)
for Horizontal or Vertical installation.
-
PRODUCT FEATURES PS10 TDController
Audio Inputs Two L&R Audio inputs. Electronically balanced, 36 kOhm. Two XLR-3F connectors.
Sense Inputs Three Amplifier Sense Inputs (PS10 L&R, LS500). 150 kOhm. 6 Pole Removable Strip Terminal.
Audio Outputs Two L&R PS10 Audio outputs. Electronically balanced, 50 Ohm. Two XLR-3M.
One Mono (L+R) LS500 Audio output. Electronically balanced, 50 Ohm. One XLR-3M.
Specifications Output Level : +20 dBm Max. +19dBm Max on 1kOhm
Noise : -88 dBm (22 Hz - 22 kHz, UnWeighted). THD+N : < 0.03% Typ. 0.05 Max for +18dBm Output
Controls & Indicators Std/Max Protection Trimmer. Gain switch (back panel), 3 positions for Amps with Gain : 26 / 32 / 38 dB.
Sub On switch & Sub Gain Control. Speaker Protect LED's. Amp Sense & Peak LED's.
Power Supply 110/220 Volts (internal wiring), 50/60Hz. Earth-Lift (back panel)
Dimensions & Weight 1U 19" Rack. 190mm (7.5") Depth. 2.9 kg (6.6 Lbs) net
