Page 14/54 RS18 GENERAL INSTRUCTIONS
• Fill each screw hole with Loctite 243 or equivalent.
• Tighten the 6 screws alternately, at the rate of 4 revolutions per screw.
• Fill each screw hole with Loctite 243
TM
or equivalent.
• Insert the 8 Handles washers and screws and tight them.
INSTALLING CARPETED RS18 RIGGING PLATES
IMPORTANT
RS18 handles must not be used to fly RS18’s (through illegal use of straps for example)
To Next Page
