Nexo RS18

RS18 TECHNICAL SPECIFICATIONS Page 45/54
9 RS18 TECHNICAL SPECIFICATIONS
9.1 System specifications
RS18 PRODUCT FEATURES
Components 2 x 18” (46cm) long excursion neodymium 8Ω drivers
Height x Width x Depth 520 x 1403 x 732mm (20.46” x 55.24” x 28.81”) with handles
520 x 1238 x 732mm (20.46” x 49.92” x 28.81”) without handles
Shape Rectangular
Weight Net Weight with handles 105Kg (231.5 lbs)
Net Weight with rigging system 126Kg (278 lbs)
Net Weight without accessories 90Kg (199 lbs)
Connectors 4 x NL4MP SPEAKON 4 pole on two connection plates (In & Through)
Construction Baltic Birch ply finish with structured black coating
Dark grey carpet finish also available
RS18 with NX242-ES4 TDcontroller or NXAMP SYSTEM SPECIFICATION
Omni Directional
Frequency Response @ -3db [a] 32Hz–100Hz 32Hz-100Hz
Usable Range @ -6db [a] 29Hz–250Hz 29Hz–150Hz
Sensitivity 1W @ 1m [b] 105dB SPL Nominal 103dB SPL Nominal
Peak SPL @ 1m [b] 143–146dBPeak
(2x1000 to 2x2000W/8Ω)
140–143dBPeak
(2x1000 W to 2x2000W/8Ω)
Dispersion Omni & Directional pattern over the entire useable bandwidth depending on the NX242
or NXAMP TDcontrollers setup. (two channels of the NX242ES4 or NXAMP are
required to process directional setups)
Directivity Index [c] 1.5<Q<2 1.7dB<DI<3dB Q=4.3 DI=5.3dB
Crossover Frequency:
NX242 or NXAMP preset dependent
From 75Hz to 100Hz From 75Hz to 100Hz
Nominal Impedance 2 x 8Ω 2 x 8Ω
Recommended Amplifiers 2 amplifier channels for directional mode
operation, each rated at 1000 to 2000 Watts
into 8Ω per channel
or 1 amplifier channel for omni mode
operation, rated at 2000 to 4000 Watts into
4Ω
2 amplifier channels for directional mode
operation, each rated at 1000 to 2000
Watts into 8Ω per channel
SYSTEM OPERATION
Electronic Controller NX242ES4 Digital TDcontroller & NXAMP Powered Digital TDcontroller presets are
precisely matched to RS18 and include sophisticated protection systems.
Using RS18 without a properly connected TDController will result in poor sound quality
and can damage components.
Speaker Cables 1-/1+ = Right or Rear
2-/2+ = Left or Front
The RS18 must use separate cables to the main system
Accessories Bumper – Flying Plates – Dolly - Front Wheel Board
Rigging system [d] Please refer to the user manual before any operation
SHIPPING & ORDERING
Packaging RS18s are packaged individually.
Order RS18-C (finished grey carpeting) or RS18-P (finished in black structured coating)
As part of a policy of continual improvement, NEXO reserves the right to change specifications without notice.
[a] Response curves and data: anechoic far field above 200 Hz, half-space anechoic below 200 Hz.
[b] Sensitivity & peak SPL: will depend on spectral distribution. Measured with band limited pink noise.
Refers to the specified +/- 3 dB range. Data are for speaker + processor + recommended amplifier combinations.
[c] Directivity curves and data: 1/3 octave smoothed frequency response, normalized to on-axis response. Data obtained by computer processing of off-axis
response curves.
[d] Please refer to the RS18 user Manual.
